Main features: Light source:
Color light: 672 RGB LED
White light: 112 WW LED
Power: 420W
Beam Angle: Color beam
Angle: 101° White beam Angle: 108°
Spot Angle: Color spot Angle: 149° White spot Angle: 152°
Color light zone 32 can be controlled separately, white light zone 16 can be controlled separately Excellent mixing function
Strong high output strobe effect built-in splicing pin, can achieve fast splicing alignment
Electronic atomization effect 0-100% smooth dimming function optical system
Efficient optical system Control and program 4 touch buttons
Control panel: 1.77 color screen display
Control protocol: DMX512, RDM
DMX channel mode: 11
Control channels: 7/15/21/39/112/17/33/65/68/117/70
Software upgrade: Update the software via DMX connection major function Press the [MENU] button to enter the main menu.
Use the [ENTER], [UP], and [DOWN] keys to browse the menu.
To select a menu option or confirm the selected Settings, press the [ENTER] button.
To return to the previous level of the menu without making any changes, press the [MENU] button or wait for a period of time to exit automatically.
